Page(s) 1-6
Shepard Road
FROM
Randolph Ave
TO
Sumac St
| Cross Sections | 1987-04-13 Page(s) 7-11
Bay St
FROM
Butternut Ave
TO
Stewart Ave
| Locations & X-Secs | 1989-04-14 Page(s) 12-13
Riverside Add Alley Blk 1
FROM
Bounded by Butternut & Stewart Ave & Bay St
| Locations & X-Secs | 0000-00-00 Page(s) 14-15
Shepard Rd Corragated Tunnel
| Locations & X-Secs | 1990-05-02 Page(s) 16
Drake St & Shepard Rd
| Rail Location | 1990-05-24 Page(s) 17-22
Edgecumbe Rd
FROM
Bayard Ave
TO
South of Shepard Rd
| Traverse for Topo | 1990-12-06 Page(s) 23
Shepard Rd
FROM
Hwy 35E
TO
300 ft East
| CL Profile | 0000-00-00 Page(s) 24
KERN Topo Test
| Topo Test | 1991-03-29 Page(s) 25
Bay St & Butternut Ave
| MH Invert Shots | 1992-06-04 Page(s) 26
Shepard Rd
FROM
SW Cor Randolph Ave
TO
795 Butternut Ave
| Bench Marks | 1992-06-22 Page(s) 27-29
Blank Pages
FROM
Blank
TO
Blank
| Blank | 0000-00-00 Page(s) 30-32
Crosby Park off of Shepard Road
| Traverse&Ties Mt 279 | 1990-12-17 Page(s) 33-34
South of Shopard Rd Along I-35-E
FROM
Shepard Rd & 35E
TO
Rebar Pt # 1239
| Cross Sections | 1991-07-18 Page(s) 35-36
Hwy 35E & Shepard Rd
| BMs & Stake Elevs | 0000-00-00 Page(s) 37-39
Elway St & Shepard Rd
| Swr & Gas Main Elevs | 1992-03-25 Page(s) 40-41
Otto Ave & Shepard Rd
| Sub Grade Elevation | 1992-05-01 Page(s) 42-43
Shepard Rd
FROM
Station 15+45
TO
Station 22+06
| X-Secs & AZ Builts | 1992-05-08 Page(s) 44
Hwy 35E & Shepard Rd Retain Wall
| Elev for Br Ret Wall | 1992-05-18 Page(s) 45-46
Shepard Rd Sewer
FROM
MH # 8
TO
MH # 205
| Sewer Elevations | 1992-05-18 Page(s) 47
Area of Duke St & Shep Rd & Randolph Ave
| Bench Marks | 1992-05-19 Page(s) 48-53
Shepard Rd Storm Sewer
| X-Secs & Elevations | 1992-06-07 Page(s) 54
Shepard Rd Bridge @ 35-E
FROM
Station 0+00
TO
Station 0+64.11
| Swr Levels & BMs | 1992-06-18 Page(s) 55-62
Shepard Rd Storm Sewer
FROM
Outlet Spout
TO
MH # 347
| Levels & BMs & Bends | 1992-06-18 Page(s) 63-64
Otto Ave
FROM
West
| CB Staking | 1992-09-14 Page(s) 65
Near Shepard & Crosby Lk Rds
| Pond Traverse | 1992-08-12 Page(s) 66
Shepard Rd Near Mile Post Marker 103
| Angles & Calculation | 1994-04-27 Page(s) 66
Shepard Rd Rebar # 1300
| Angle to Rebar 1300 | 1994-05-19 Page(s) 67
Shepard Rd Bridge
FROM
TP 1
TO
NW Cor Br Pier(3rd from River)
| Hubs for Arch Pipe | 1994-05-23 Page(s) 68-80
Blank Pages
FROM
Blank
TO
Blank
| Blank | 0000-00-00
