Page(s) 1
Phalen Branch Belt Line
| BMs | 0000-00-00
1
Page(s) 3-6
Clarence St
FROM
Jessamine Ave
TO
McAfee St
| BMs | 0000-00-00 Page(s) 6
Clarence St
FROM
Arlington Ave
TO
Ivy Ave
| Sewer Grades & Map | 0000-00-00 Page(s) 7
Clarence St
FROM
McAffee St
TO
Arlington Ave
| Y Branch Locations | 0000-00-00 Page(s) 8
Clarence St
FROM
1st MH N of Maryland Ave
TO
McAfee St
| Sewer Grades | 0000-00-00 Page(s) 9-12
Clarence St
FROM
Ivy Ave
TO
Arlington Ave
| Sewer Grades | 0000-00-00 Page(s) 13
McAfee St
FROM
Clarence St
TO
Arlington Ave
| Sewer Grades | 0000-00-00 Page(s) 14-16
McAfee St
FROM
Low Pt of McAfee St
TO
Arlington Ave
| Sewer Grades | 0000-00-00 Page(s) 17
Arlington Ave
FROM
McAfee St
TO
English St
| Sewer Grades | 0000-00-00 Page(s) 18
Nebraska Ave
FROM
Chamber St
TO
Atlantic St
| Sewer Loc & Grades | 0000-00-00 Page(s) 19-22
Atlantic St
FROM
Nebraska Ave
TO
Larpenteur Ave
| Sewer Loc & Grades | 1955-04-26 Page(s) 23-26
Chamber St
FROM
Nebraska Ave
TO
Larpenteur Ave
| Y Branch Loc&Grades | 1955-04-27 Page(s) 27-28
Duluth St
FROM
Larpenteur Ave
TO
Montana Ave (Produced)
| Sewer Loc & Grades | 0000-00-00 Page(s) 29-31
East Shore Drive
FROM
Idaho Ave
TO
Larpenteur Ave
| Y Branch Loc&Grades | 0000-00-00 Page(s) 32
Idaho Ave
FROM
Duluth St
TO
E Shore Drive
| Sewer Grades | 1955-04-05 Page(s) 33
Larpenteur Ave
FROM
Duluth St
TO
245.5 ft west
| Y Branch Loc&Grades | 0000-00-00 Page(s) 34
Brighton Place
FROM
Duluth St
TO
240.3 ft west
| Y Branch Loc&Grades | 0000-00-00 Page(s) 35-36
Arlington Ave
FROM
East
| Y Branch Loc&Grades | 0000-00-00 Page(s) 38
An Easement
FROM
Atlantic Ave
TO
Duluth St
| Storm Drain Grades | 1955-04-14 Page(s) 38
A Temporary Easement
FROM
Atlantic Ave
TO
Duluth St
| Sewer Grades | 0000-00-00 Page(s) 39
Duluth St
FROM
An Easement
TO
Hoyt Ave
| Y Branch Locations | 0000-00-00 Page(s) 40-41
E Shore Drive
FROM
Hoyt Ave
TO
Larpenteur Ave
| Sewer Grades | 0000-00-00 Page(s) 42
Duluth St
FROM
Hoyt Ave
TO
Brighton Place
| Y Branch Loc&Grades | 1955-04-25 Page(s) 43
Hoyt Ave
FROM
Duluth St
TO
E Shore Drive
| Sewer Grades | 1955-04-26 Page(s) 44
Easement Storm Drain
FROM
Chamber St (187 ft W of Duluth St)
TO
8 ft east of Duluth St
| Y Branch Loc&Grades | 1955-04-26 Page(s) 45-46
East Shore Drive
FROM
Hoyt Ave
TO
South
| Sewer Grades | 1955-04-27 Page(s) 47-48
Storm Sewer on Easement
FROM
Duluth St
TO
Chamber St
| Sewer Grades | 1955-04-29 Page(s) 49-53
Atlantic Ave
FROM
Hoyt Ave
TO
Larpenteur Ave
| Sewer Grades | 1955-05-04 Page(s) 54-57
Duluth St
FROM
Montana Ave (Produced)
TO
Larpenteur Ave
| Sewer Grades | 1955-05-10 Page(s) 58
Arlington Ave & English St
| Sewer Grades | 1955-05-19 Page(s) 59-60
Chamber St
FROM
Nebraska Ave
TO
Larpenteur Ave
| Sewer Grades | 1955-05-31 Page(s) 61
Hoyt Ave
FROM
Duluth St
TO
250 ft west
| Sewer Grades | 0000-00-00 Page(s) 62-69
English St
FROM
Nebraska Ave
TO
Larpenteur Ave
| Sewer Grades | 0000-00-00 Page(s) 70-78
Clarence St
FROM
341'N of Maryland Ave
TO
623'N of Maryland Ave
| Y Branch Loc&Grades | 1955-06-06 Page(s) 79
Clarence St
FROM
Prosperity Ave
TO
Maryland Ave
| Test Piles&Levels | 1954-11-23
